aluminium foil alloy 1235

Product introduction
1235 aluminium foil is the aluminium foil of aluminium content not less than 99.35% , Signi Aluminium can process 0.018-0.5mm thickness of 1235 aluminium foil, because this product has excellent rust resistance, formability, dissolving ability ,then it is widely used in cable, tape, battery foil,etc.

Signi Aluminium stocks a variety of aluminium foil grades and sizes tailored to your needs and specifications.

Send us email

Specification

Performance

Application

1235 aluminium foil Technical Parameters

Alloy	1235 aluminium foil
Temper	O、H18
Thickness（mm）	0.018-0.2
Width（mm）	100-1600
Length（mm）	C
Typical products	Cable, tape, battery foil., etc.

Chemical Composition of 1235 aluminium foil：

Si	Fe	Cu	Mn	Mg	V	Zn	Ti	Others		Al
								Individual	Total
Si+Fe 0.65		0.05	0.05	0.05	0.05	0.10	0.06	0.03	-	99.35

Mechanical propertiesof 1235 aluminium foil：

Alloy	Product Type	Temper	Thickness (mm)	Tensile Strength （Mpa）	Elongation (%) A100mm
1235	Food and Household Foil	O	0.01-0.024	40-100	≥1
			0.025-0.04	45-100	≥2
			0.041-0.07	45-100	≥4
		H18	0.01-0.07	≥135	-
	aluminium foil for capacitor industry	H18	0.02-0.05	≥135	-
	aluminium foil for cable industry	O	0.01-0.024	40-100	≥1
			0.025-0.04	45-100	≥2
			0.041-0.07	45-100	≥4
	aluminium foil for adhesive tape industry	O	0.012-0.04	50-90	≥1
		H18	0.012-0.04	≥135	-
		O	0.03-0.07	60-100	≥2
